Industrial Relay 240 VAC 2.5 VA
Tekniske data
| Kontakter | 2 sluttende (NO) |
| Ucoil | 240 VAC |
| Rcoil | 21000 Ω |
| Pcoil | 2.5 VA |
| Switchet spænding | 250 VAC |
| Switchet strøm | 25 A@ 220 VAC |
| Switcheffekt | 5500 VA |
| Kontaktmateriale | Ag legeret |
| Prøvspænding | 4 kV |
| Dimensioner L x B x H | 68.5 x 33.5 x 47 mm |
| Temperaturområde | -25...+60 °C |
Produktfamiliebeskrivelse
No contact chattering for momentary voltage drops up to 50% of rated voltage
Wide-range AC-activated coil that handles 100 to 120 VAC or 200 to 240 VAC at either 50 or 60 Hz
Particularly for inductive loads suited
Flameresistant insulation materials corresponding to UL94V-0
Quick-connect terminals 6.35 x 0.8 mm
Accessories for various connecting and mounting styles available
Approvals for UL, CSA, TUV
Meets IEC950
8 mm clearance and creepage distance
- v/5 – Kr. 186,25
- v/10 – Kr. 164,06
