El-Capacitor 100µF/250V-P7,5-16x32
Varenummer:
133-453
Varekode: CSHT0100/250-P7,5
Vægt: 12 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Specifikationer
| Kondensator-type | radial |
|---|---|
| Produkt | kondensator |
| Spænding, max. | 250 V |
| Tolerance | ±20 % |
| Temperatur | -40 – 105 °C |
| Højde | 3.2 cm |
| Diameter | 1.6 cm |
| Benafstand | 7.5 mm |
| Kapacitans | 100 µF |
- CAP, ALU ELEC, 100UF, 250V, RAD
- Product Range: PANASONIC - EE Series
- Capacitance: 100µF
- Capacitance Tolerance: ± 20%
- Voltage Rating: 250V
- Diameter: 16mm
- ESR: -
- Height: 31.5mm
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 7.5mm
- Lifetime @ Temperature: 10000 hours @ 105°C
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Packaging: -
- SVHC: No SVHC (16-Dec-2013)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 31.5mm
- No. of Pins: 2
- Operating Temperature Range: -25°C to +105°C
- Ripple Current AC: 2100mA
- Ripple Current Frequency: 100kHz
Inkl. moms
Kr. 34,38
- v/10 – Kr. 31,25
- v/100 – Kr. 26,44
