El-Capacitor 2,2µF/350V-P3,5-8x12
Varenummer:
133-201
Varekode: CS0002,2/350-P3,5
108 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Specifikationer
| Kondensator-type | radial |
|---|---|
| Produkt | kondensator |
| Temperatur | -40 – 85 °C |
| Spænding, max. | 350 V |
| Tolerance | ±20 % |
| Kapacitans | 2.2 µF |
| Højde | 1.2 cm |
| Diameter | 8 mm |
| Benafstand | 3.5 mm |
- ECA2VM2R2
- CAP, ALU ELEC, 2.2UF, 350V, RAD
- Product Range: PANASONIC - M Series
- Capacitance: 2.2µF
- Capacitance Tolerance: ± 20%
- Voltage Rating: 350V
- Diameter: 8mm
- ESR: -
- Height: 12mm
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 3.5mm
- Life Time @ Temperature: 2000 hours @ 85°C
- Operating Temperature Min: -25°C
- Operating Temperature Max: 85°C
- Packaging: -
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 12mm
- Lead Diameter: 0.6mm
- Operating Temperature Range: -25°C to +85°C
- Ripple Current AC: 50mA
Inkl. moms
Kr. 3,75
- v/10 – Kr. 3,44
- v/100 – Kr. 3,12
- v/1000 – Kr. 2,81
Produktfiler
