PNP 250V 0,5A 2W TO202
ype Designator: BF760
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 2 W
Maximum Collector-Base Voltage |Vcb|: 250 V
Maximum Collector-Emitter Voltage |Vce|: 250 V
Maximum Emitter-Base Voltage |Veb|: 6 V
Maximum Collector Current |Ic max|: 0.5 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 20 MHz
Collector Capacitance (Cc): 3 pF
Forward Current Transfer Ratio (hFE), MIN: 40
Noise Figure, dB:
Package: TO202
- v/10 – Kr. 10,00
- v/25 – Kr. 7,50
