SPS Case 151W 54/53,5V
Varenummer:
129-453
Varekode: AD-155C
0 stk.
på lager
Gruppe: L6715
MEANWELL Switching Power Supplies
Series: AD-155
Case, With Battery Charger (UPS Function)
Output: 151W
| Features |
| • Enclosed case, screw terminals • Universal input • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Batterie low protection |
 |
| Technical Specifications |
| |||||||||||||||||||||||
| Input Voltage: | 88...264V AC (47...63Hz) | 124...370V DC | Input Inrush Current, Max.: | 40A | Leakage Current, Max.: | 1mA | Over Load Protection: | 105...135% | Withstand Voltage | I/P-O/P: | 3000V AC | I/P-FG: | 1500V AC | O/P-FG: | 500V AC | Operating Temperature: | -10...+60°C | Weight: | 880g | ||||
| I/P = Input, O/P = Output, FG = Frame Ground | |||||||||||||||||||||||
| |||||||||||||||||||||||
| Part Nr. | UA | IA | PA1) | Uadj | DUA | URN | h | [V] | [A] | [W] | [V] | [%] | [mVp-p] | [%] | AD-155A | 13,8 | 0...11,5 | 151,55 | 12...14,5 | 2 | 150 | 80 | 13,3 | 0...0,5 | AD-155B | 27,6 | 0...5,5 | 151,55 | 24...29 | 1 | 150 | 84 | 27,1 | 0...0,5 | |||||||||||||||||||||
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency, 1) The Sum of the Power Used by the Individual Channels Must Not Exceed the Total Power Rating. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Note |
| You will find installation material in product group L6911. |
|
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
