SPS Case 300W 48V/6,25A
Varenummer:
129-442
Varekode: SPV-300-48
Vægt: 1094 g
0 stk.
på lager
Gruppe: L6514
MEANWELL Switching Power Supplies
Series: SPV-300
Case, Programmable Single Output
Output: 300W
MEANWELL Switching Power Supplies
Series: SPV-300
Case, Programmable Single Output
Output: 300W
| Features |
| • Enclosed case, built-in fan, screw terminals • Universal input • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Built-in active PFC function • Built-in remote On/Off control • Output voltage programmable 20...110% by external control signal 1...5,5V DC |
 |
| Technical Specifications |
| |
| Input Voltage: | 88...264V AC (47...63Hz) |
| 124...370V DC | |
| Input Inrush Current, Typ.: | 40A |
| Leakage Current, Max.: | 1mA |
| Output Voltage Adjustment: | -15...+10% |
| Over Load Protection: | 105...135% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 1500V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -20...+65°C |
| Weight: | 1100g |
| I/P = Input, O/P = Output, FG = Frame Ground | |
| |
| Part Nr. | UA | IA | PA | DUA | URN | h |
| Â | [V] | [A] | [W] | [%] | [mVp-p] | [%] |
| SPV-300-12 | 12 | 0...25 | 300 | 1 | 150 | 83,5 |
| SPV-300-24 | 24 | 0...12,5 | 300 | 1 | 150 | 85 |
| SPV-300-48 | 48 | 0...6,25 | 300 | 1 | 240 | 86,5 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
| ||||||
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
Inkl. moms
Kr. 1125,00
- v/5 – Kr. 1000,00
- v/10 – Kr. 875,00
