Videosender
Varenummer:
124-202
Varekode: AV-5820TX
Vægt: 565 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
| Type | transmitter, 25 mW |
| Frequency | 5.8 GHz |
| Video signal | 1 Vpp/75 Ω |
| Audio signal | 0.1-10 V, adjustable |
| Type of antenna | PCB |
| Video bandwidth | 30 Hz-5 MHz |
| Audio bandwidth | 15 Hz-15 kHz |
| Audio transmission | stereo |
| Max. operating range | |
Indoors | approx. 30-40 m |
Outdoors | 500 m |
| Power supply | 8-30 V DC current /250 mA at 12 V DC current |
| Dimensions | 170x70x135 mm |
| Protective class | IP54 |
| Admiss. ambient temp. | -10 °C to +55 °C |
| Weight | 350 g |
| Connections | |
Video | spring-load. term. |
Audio | spring-load. term. |
DCF | - |
Power supply | spring-load. term. |
Control channel | spring-load. term. |
For professionals who are not satisfied with three wireless transmission channels in the standard frequency range of 2.4GHz, we now offer this 5.8GHz video/audio wireless system. It operates with a radiation efficiency of 25mW and is able to perform encoded transmission of up to 16 channels. Transmitter unit for the transmission of video and audio signals, 5.8 GHz, 25 mW, 16 channels
- Stereo audio transmission
- Adjustable audio level
- Video picture inversion
- Connection for control channel
- Momentary push-button for channel selection
- Weatherproof ABS housing with pole mount
Inkl. moms
Kr. 3799,00
