1 x skifte relæ 24VDC 10A 1113R, PLUG-IN-RELAY
Varenummer:
123-814
Varekode: G2R-1-S-DC24(S)
Vægt: 23 g
10 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere 2512 stk. kan skaffes onsdag d. 4/11
Specifikationer
| Relæ kontakt | SPDT |
|---|---|
| Spolespænding | 24 V |
| Spolemodstand | 1.113 kΩ |
| Mærkestrøm | 10 A |
- PLUG-IN RELAY, CONTACTS SPDT
- Relay Type: Power
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 10A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 30V
- Coil Resistance: 1.113kohm
- Contact Configuration: SPDT
- Coil Type: DC
- Coil Current: 21.8mA
- Nom Operating Power: 530mW
- Relay Mounting: Quick Connect
- External Height: 25.5mm
- External Width: 29mm
- External Depth: 13mm
- SVHC: No SVHC (18-Jun-2012)
- Contact Current AC Max: 10A
- Contact Current DC Max: 10A
- Contact Voltage AC Max: 250V
- Contact Voltage DC Max: 30V
- External Length / Height: 25.5mm
- Mounting Type: Plug-In
- No. of Poles: 1
- Series: G2R
Inkl. moms
Kr. 61,50
- v/10 – Kr. 50,00
Produktfiler
1 x skifte relæ 24VDC 10A 1113R, PLUG-IN-RELAY
123-814
/ G2R-1-S-DC24(S)
10 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Ved bestilling nu, får vi dem hjem onsdag d. 4/11
Specifikationer
- Relæ kontakt SPDT
- Spolespænding 24 V
- Spolemodstand 1.113 kΩ
- Mærkestrøm 10 A
- PLUG-IN RELAY, CONTACTS SPDT
- Relay Type: Power
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 10A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 30V
- Coil Resistance: 1.113kohm
- Contact Configuration: SPDT
- Coil Type: DC
- Coil Current: 21.8mA
- Nom Operating Power: 530mW
- Relay Mounting: Quick Connect
- External Height: 25.5mm
- External Width: 29mm
- External Depth: 13mm
- SVHC: No SVHC (18-Jun-2012)
- Contact Current AC Max: 10A
- Contact Current DC Max: 10A
- Contact Voltage AC Max: 250V
- Contact Voltage DC Max: 30V
- External Length / Height: 25.5mm
- Mounting Type: Plug-In
- No. of Poles: 1
- Series: G2R
Produktfiler
