SPS Class2 PFC 96W 24V/4A
AC-DC Single output LED driver Constant Voltage (CV)
- Universal input, screw terminals
- Plastic housing
- Overload protection by current limiting, auto recovery
- Protected against short circuit, overload, overvoltage
- Built-in PFC circuit
- For LED and lighting applications
- UL1310 Class 2
- Adjustable output voltage
- Adjustable current limit
Output 24Vdc at 4A
I/O screw terminal block
LED EN 61347
Net weight 520g
Constant Current C.C.
Constant Voltage C.V.
Enclosed Plastic housing
Output Power (W): 96
Output Voltage (V): 24
Output Current (A): 4
Input Voltage (V): 110/230 universal input 90 - 264
Width (mm): 70.5
Height (mm): 35
Depth (mm): 200.5
No Dimming
Housing Type: Plastic
Input Voltage: 90...264V AC (47...63Hz)
127...370V DC: Input Inrush Current, Max.: 40A
I/P-O/P: 3750V AC
I/P-FG: 2000V AC
O/P-FG: 500V AC
Operating Temperature: -30...+50°C
Dimensions(LxWxH): 200,5x69,5x35mm
Weight: 520g
