WW Resistor Metal Housed 10W 1% 0R05
Varenummer:
120-905
Varekode: RH01000R05
Vægt: 7 g
32 stk.
på lager
Specifikationer
| Produkt | modstand |
|---|---|
| Komponenthus | metal |
| Effekt, max. | 10 W |
| Tolerance | ±1 % |
| Modstand | 0.05 Ω |
Gruppe: C1643
VISHAY Wirewound Resistors, Aluminum Housed
Series: RH010
Style: Bulk
Power: 10W
Tolerance: 1,0%
Features
| • Hermetically sealed design aluminum housed • Heat sink with high thermal contuctivity • Mounts on chassis to utilize heat-sink effect • Spot-welded compounds • Meets applicable requirements of MIL-PRF-18546 |
 |
| Technical Specifications |
|
|
| Resistance Tolerance: | ±1,0% |
| Power Rating (25°C): | 25W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance, Min.: | 103MOhm |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/°C |
| 1R...9R9: | ±50ppm/°C |
| from 9R9: | ±20ppm/°C |
| Temperature Range: | -55...+250°C |
| Terminal Strength, Min.: | 10lb |
| Derating: | Linear 25°C to 250°C (0W) |
|
|
Produktfiler
WW Resistor Metal Housed 10W 1% 0R05
120-905
/ RH01000R05
32 stk.
på lager
Specifikationer
- Produkt modstand
- Komponenthus metal
- Effekt, max. 10 W
- Tolerance ±1 %
- Modstand 0.05 Ω
Gruppe: C1643
VISHAY Wirewound Resistors, Aluminum Housed
Series: RH010
Style: Bulk
Power: 10W
Tolerance: 1,0%
Features
| • Hermetically sealed design aluminum housed • Heat sink with high thermal contuctivity • Mounts on chassis to utilize heat-sink effect • Spot-welded compounds • Meets applicable requirements of MIL-PRF-18546 |
|
| Technical Specifications |
|
|
| Resistance Tolerance: | ±1,0% |
| Power Rating (25°C): | 25W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance, Min.: | 103MOhm |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/°C |
| 1R...9R9: | ±50ppm/°C |
| from 9R9: | ±20ppm/°C |
| Temperature Range: | -55...+250°C |
| Terminal Strength, Min.: | 10lb |
| Derating: | Linear 25°C to 250°C (0W) |
|
|
