Thermal Fuses 130°C 2A Radial
Varenummer:
120-207
Varekode: A4-F
Vægt: 0 g
150 stk.
på lager
Bestil inden kl. 14 i dag for afsendelse i dag
Yderligere kan skaffes lørdag d. 24/10
Specifikationer
| Strøm, max. | 2 A |
|---|---|
| Temperatur | 130 °C |
Gruppe: E1135
Micro-Thermal Cut-off Fuses
Series: A-F
Radial
Rated Current: 2A
| Features |
| • Thermal Cutoffs designed to provide temperature protection of thermally sensitive devices • Non-resettable |
 |
| Technical Specifications |
|
|||||||||
| Contact: | NC | Housing: | Epoxy Resin | Rated Voltage: | 250V | Rated Current: | 2A | ||
|
|||||||||
| Artikel | TRated | TH | TMax | TSwitch-off | [°C] | [°C] | [°C] | [°C] | A1-F | 102 | 79 | 203 | 98±2 | A2-F | 115 | 92 | 203 | 112±3 | A3-F | 125 | 101 | 203 | 120±3 | A4-F | 130 | 107 | 203 | 126±2 | A5-F | 135 | 112 | 203 | 131±3 | ||||||
| TRated = Rated Temperature, TH = Continuous Operating Temperature, TMax = Max. Limiting Temperature, TSwitch-off = Switch-off Temperature | |||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
| Approvals |
 Nr. 40008720  E140847 Nr. 14007445 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
| Various |
|
