WW Resistor Metal Housed 10W 1% 1K
Varenummer:
119-255
Varekode: RH0101K000
Vægt: 6 g
0 stk.
på lager
Specifikationer
| Produkt | modstand |
|---|---|
| Komponenthus | metal |
| Modstand | 1 kΩ |
| Effekt, max. | 10 W |
| Tolerance | ±1 % |
Gruppe:
C1643
VISHAY Wirewound Resistors, Aluminum Housed
Series: RH010
Style: Bulk
Power: 10W
Tolerance: 1,0%
VISHAY Wirewound Resistors, Aluminum Housed
Series: RH010
Style: Bulk
Power: 10W
Tolerance: 1,0%
| Features |
| Hermetically sealed design aluminum housed Heat sink with high thermal contuctivity Mounts on chassis to utilize heat-sink effect Spot-welded compounds Meets applicable requirements of MIL-PRF-18546 |
 |
| Technical Specifications |
| |
| Resistance Tolerance: | ±1,0% |
| Power Rating (25C): | 10W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance: | >103MW |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/C |
| 1R...9R9: | ±50ppm/C |
| >9R9: | ±20ppm/C |
| Temperature Range: | -55...+250C |
| Terminal Strength, Min.: | 5lb |
| Derating: | Linear 25C to 250C (0W) |
| |
| Labelling |
| Manufacturer logo, series, resistance value, tolerance |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces Form of delivery: Bulk |
|
| Manufacturer |
 |
| http://www.vishay.com |
|
Produktfiler
