Piezo Siren 12V 2,3-3,5kHz 105dB
Varenummer:
117-681
Varekode: PS532Q
Vægt: 107 g
2 stk.
på lager
Gruppe:
H1511
HITPOINT Piezo Sirens
Series: PS5, PS6
HITPOINT Piezo Sirens
Series: PS5, PS6
| Features |
| Very high sound output, High reliability and long life |
 |
| PS523AQ |
| Piezo Siren with High and Low Tones |
|
| Technical Specifications |
| |
| Operating Voltage: | 12V DC |
| Operating Frequency: | 1,5...4,0kHz |
| Current Consumption: | 200mA/12V DC |
| S.P.L.1): | 105dB/12V DC |
| Pulse Rate: | 4,5Hz±20% |
| Operating Temperature: | -20...+70C |
| Storage Temperature: | -30...+80C |
| 1) Within 1m Range | |
| |
| PS532Q, PS552Q |
| Dual Tone Piezo Sirens with Changing Tones |
|
| Technical Specifications |
| |
| Operating Voltage: | 12V DC |
| Operating Frequency: | 2,3...3,5kHz |
| Current Consumption: | 200mA/12V DC |
| S.P.L.1): | 105dB/12V DC |
| Pulse Rate: | 1,2Hz±20% |
| Operating Temperature: | -20...+70C |
| StorageTemperature: | -30...+80C |
| 1) Within 1m Range | |
| |
| PS693Q |
| Piezo Siren with High and Low Tones |
|
| Technical Specifications |
| |
| Operating Voltage: | 12V DC |
| Operating Frequency: | 1,5...3,8kHz |
| Current Consumption: | 200mA/12V DC |
| S.P.L.1): | 110dB/12V DC |
| Pulse Rate: | 3,3Hz±20% |
| Operating Temperature: | -20...+70C |
| StorageTemperature: | -30...+80C |
| 1) Within 1m Range | |
| |
| PS583Q |
| Piezo Siren with High and Low Tones |
|
| Technical Specifications |
| |
| Operating Voltage: | 12V DC |
| Operating Frequency: | 1,5...3,5kHz |
| Current Consumption: | 300mA |
| S.P.L.1): | 100dB |
| Pulse Rate: | 3,3Hz±20% |
| Operating Temperature: | -20...+70C |
| StorageTemperature: | -30...+80C |
| 1) Within 1m Range | |
| |
| PS593SCQ |
| Piezo Sirens with High and Low Tones |
|
| Technical Specifications |
| |
| Operating Voltage: | 12V DC |
| Operating Frequency: | 1,5...3,5kHz |
| Current Consumption: | 250mA |
| S.P.L.1): | 115dB |
| Pulse Rate: | 3,3Hz±20% |
| Operating Temperature: | -20...+70C |
| StorageTemperature: | -30...+80C |
| 1) Within 1m Range | |
| |
| Labelling |
 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.hitpoint.com.tw |
|
