Trådviklet modstand 50W 1Ω ±1 %
Varenummer:
117-431
Varekode: HS50-1RF
Vægt: 28 g
4 stk.
på lager
Specifikationer
| Produkt | modstand |
|---|---|
| Komponenthus | aluminium |
| Effekt, max. | 50 W |
| Modstand | 1 Ω |
| Tolerance | ±1 % |
Features
| • Hermetically sealed design aluminum housed • Heat sink with high thermal contuctivity • Mounts on chassis to utilize heat-sink effect • Spot-welded compounds • Meets applicable requirements of MIL-PRF-18546 |
 |
| Technical Specifications |
|
|
| Resistance Tolerance: | ±1,0% |
| Power Rating (25°C): | 50W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance, Min.: | 103MOhm |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/°C |
| 1R...9R9: | ±50ppm/°C |
| from 9R9: | ±20ppm/°C |
| Temperature Range: | -55...+250°C |
| Terminal Strength, Min.: | 10lb |
| Derating: | Linear 25°C to 250°C (0W) |
Produktfiler
Trådviklet modstand 50W 1Ω ±1 %
117-431
/ HS50-1RF
4 stk.
på lager
Specifikationer
- Produkt modstand
- Komponenthus aluminium
- Effekt, max. 50 W
- Modstand 1 Ω
- Tolerance ±1 %
Features
| • Hermetically sealed design aluminum housed • Heat sink with high thermal contuctivity • Mounts on chassis to utilize heat-sink effect • Spot-welded compounds • Meets applicable requirements of MIL-PRF-18546 |
|
| Technical Specifications |
|
|
| Resistance Tolerance: | ±1,0% |
| Power Rating (25°C): | 50W |
| Operating Voltage, Max.: | (PxR)1/2 |
| Insulation Resistance, Min.: | 103MOhm |
| Insulation Voltage: | 1000Vrms |
| Temperature Coefficient | |
| 0R1...0R99: | ±100ppm/°C |
| 1R...9R9: | ±50ppm/°C |
| from 9R9: | ±20ppm/°C |
| Temperature Range: | -55...+250°C |
| Terminal Strength, Min.: | 10lb |
| Derating: | Linear 25°C to 250°C (0W) |
Produktfiler
