DC Gear Motor 24V 144W 20rpm 20Nm
Varenummer:
116-286
Varekode: 25937103B00
Vægt: 5 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Gruppe:
P3512
DOGA DC Geared Motors
Series: 258/259
DOGA DC Geared Motors
Series: 258/259
| Features |
| • With worm gear • Quiet running • IP53 protection • Short stop time |
 |
| Technical Specifications |
| Part Nr. | UN | IN | MN | IA | MA | N | Weight |
| 25_ | [V] | [A] | [Nm] | [A] | [Nm] | [rpm] | [kg] |
| 837103B00 | 24 | 5 | 15 | 21 | 80 | 25 | 3 |
| 937103B00 | 24 | 6 | 20 | 30 | 130 | 22 | 5,9 |
| UN = Rated Voltage, IN = Rated Current, MN = Rated Torque, IA = Starting Current, MA = Starting Torque, N = NO-Load-Speed, Weight | |||||||
| |||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.doga.es/ |
|
Inkl. moms
Kr. 4352,06
Produktfiler
