DC Gear Motor 12V 40,8W 38rpm 2Nm
Varenummer:
116-284
Varekode: 31627612H00
Vægt: 0 g
1 stk.
på lager
Bestil nu for afsendelse i morgen
Yderligere 1 stk. kan skaffes tirsdag d. 27/10
Gruppe:
P3514
DOGA DC Geared Motors
Series: 316
DOGA DC Geared Motors
Series: 316
| Features |
| • With worm gear • Quiet running • IP40 protection • Short stop time |
 |
| Technical Specifications |
| Part Nr. | UN | IN | MN | IA | MA | N | Weight |
| 316276_ | [V] | [A] | [Nm] | [A] | [Nm] | [rpm] | [kg] |
| 12H00 | 12 | 3,4 | 2 | 12 | 10 | 38 | 0,9 |
| 13H00 | 24 | 1,7 | 2 | 6 | 10 | 38 | 0,9 |
| UN = Rated Voltage, IN = Rated Current, MN = Rated Torque, IA = Starting Current, MA = Starting Torque, N = NO-Load-Speed, Weight | |||||||
| |||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.doga.es/ |
|
Produktfiler
