SMD MLC Capacitor 100nF 10V 10% X7R 0402
Varenummer:
116-036
Varekode: CVNF100K0402
Vægt: 0 g
450 stk.
på lager
Specifikationer
| Materiale | X7R |
|---|---|
| Produkt | kondensator |
| Kondensator-type | keramisk |
| Tolerance | ±10 % |
| Spænding, max. | 10 V |
| Kapacitans | 100 nF |
| Komponenthus | 0402 |
Gruppe:
C5431
DARFON SMD Multilayer Ceramic Capacitors
Series: C1005
Type of Ceramic: X7R
Housing: 0402
DARFON SMD Multilayer Ceramic Capacitors
Series: C1005
Type of Ceramic: X7R
Housing: 0402
| Technical Specifications |
 | |
| Rated Voltage (UN) | |
| 220pF...10nF: | 50V DC |
| 10nF: | 25V DC |
| 27nF, 47nF: | 16V DC |
| 100nF: | 10V DC |
| Test Voltage: | 2,5xUN |
| Capacitance Tolerance: | ±10% |
| |
| Chip Dimensions |
| Housing | L | I | e | bmMax. |
| [mm] | [mm] | [mm] | [mm] | |
| 0402 | 1,0±0,05 | 0,5±0,05 | 0,55 | 0,3 |
| ||||
| Additional Products |
| Other articles from row E12 (5 reels min.) available on request, delivery time approx. 4 weeks. |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 500 pieces Form of delivery: orders of less than 10.000 pieces: 500 pieces on segment tape without leader tape and reel; orders of 10.000 pieces: 10.000 pieces on super-8 reel. |
|
| Manufacturer |
| Darfon http://www.darfon.com |
|
Inkl. moms
v/100
Kr. 0,50
- v/500 – Kr. 0,18
- v/4000 – Kr. 0,09
