Term.Block 250V 9-pol. (h) Grey

Varenummer: 115-073
Varekode: ARK500/9
98 stk. på lager
Bestil nu for afsendelse i morgen
Vis lignende produkter i kategorien "Lodret RM 5mm. (5,08)"
Med talmarkering: 1-2-3-4-5-6-7-8-9
Mål: 45x10x8mm.


Technical Specifications

Rated Voltage (EN 60998):
 250V
Rated Current (T60):
 17,5A
Test Voltage:
 2kV
Rated Cross Section Single Stranded Wire:
 1,5mm2
Rated Cross Section Fine Stranded Wire:
 1,5mm2
Stripped Length:
 6,0mm
Insulating Material:
 PA
Temperature Range:
 -30C...+105C
Flammability Class:
 UL94V-0
Colour:
 Dark Grey
Dimensions

Part Nr.
 L
 H
 D
[mm]
ARK500/2 10,0
 10,0
 7,5
ARK500/3 15,0
 10,0
 7,5

Approvals
EN 60998, 1059,


Manufacturer

http://www.ptr-messtechnik.de

Inkl. moms
Kr. 10,00
  • v/10 – Kr. 8,12
  • v/25 – Kr. 6,25
  • v/100 – Kr. 5,62
  1. Alle produkter
  2. Kabler, stik og adaptere
  3. Strøm
  4. Printterminaler
  5. Lodret RM 5mm. (5,08)
  6. Term.Block 250V 9-pol. (h) Grey

Term.Block 250V 9-pol. (h) Grey

115-073
/ ARK500/9
98 stk. på lager
Bestil nu for afsendelse i morgen
Kontakt os for at få oplyst leveringstid
Med talmarkering: 1-2-3-4-5-6-7-8-9
Mål: 45x10x8mm.


Technical Specifications

Rated Voltage (EN 60998):
 250V
Rated Current (T60):
 17,5A
Test Voltage:
 2kV
Rated Cross Section Single Stranded Wire:
 1,5mm2
Rated Cross Section Fine Stranded Wire:
 1,5mm2
Stripped Length:
 6,0mm
Insulating Material:
 PA
Temperature Range:
 -30C...+105C
Flammability Class:
 UL94V-0
Colour:
 Dark Grey
Dimensions

Part Nr.
 L
 H
 D
[mm]
ARK500/2 10,0
 10,0
 7,5
ARK500/3 15,0
 10,0
 7,5

Approvals
EN 60998, 1059,


Manufacturer

http://www.ptr-messtechnik.de

Kr. 10,00
  • v/10 – Kr. 8,12
  • v/25 – Kr. 6,25
  • v/100 – Kr. 5,62
