Crystal 14,7456 MHz HC-49/U
Varenummer:
113-337
Varekode: QM014,7456
72 stk.
på lager
Bestil nu for afsendelse i morgen
Vis lignende produkter i kategorien "HC-49"
 |
|
|
Temperature Range:
|
-10...+60°C
|
Frequency Tolerance (25°C):
|
±30ppm
|
Shunt Capacitance, Max.:
|
7pF
|
Drive Level:
|
1,0mW
|
Insulation Resistance (100V DC):
|
>500MW
|
Aging:
|
±5ppm/Year
|
|
|
|
|
|
|
Part Nr.
|
Frequency
|
C
|
RESR
|
Type
|
| |
[Hz]
|
[pF]
|
W
|
|
| QM001,843 |
1.843.200
|
30
|
600
|
Fundamental
|
| QM002 |
2.000.000
|
30
|
550
|
Fundamental
|
| QM002,457 |
2.457.600
|
30
|
350
|
Fundamental
|
| QM003 |
3.000.000
|
32
|
150
|
Fundamental
|
| QM003,276 |
3.276.800
|
12,5
|
150
|
Fundamental
|
| QM003,579 |
3.579.545
|
16
|
100
|
Fundamental
|
| QM003,686 |
3.686.400
|
16
|
100
|
Fundamental
|
| QM004 |
4.000.000
|
30
|
90
|
Fundamental
|
| QM004,096 |
4.096.300
|
30
|
90
|
Fundamental
|
| QM004,194 |
4.194.304
|
32
|
90
|
Fundamental
|
| QM004,915 |
4.915.200
|
16
|
90
|
Fundamental
|
| QM005 |
5.000.000
|
30
|
80
|
Fundamental
|
| QM006 |
6.000.000
|
30
|
60
|
Fundamental
|
| QM006,144 |
6.144.000
|
16
|
60
|
Fundamental
|
| QM006,553 |
6.553.600
|
30
|
60
|
Fundamental
|
| QM007,372 |
7.372.800
|
32
|
60
|
Fundamental
|
| QM008 |
8.000.000
|
30
|
50
|
Fundamental
|
| QM009,216 |
9.216.000
|
30
|
45
|
Fundamental
|
| QM009,830 |
9.830.400
|
30
|
45
|
Fundamental
|
| QM010 |
10.000.000
|
30
|
40
|
Fundamental
|
| QM010,240 |
10.240.000
|
30
|
40
|
Fundamental
|
| QM010,700 |
10.700.000
|
30
|
40
|
Fundamental
|
| QM011,0592 |
11.059.200
|
30
|
40
|
Fundamental
|
| QM012 |
12.000.000
|
30
|
35
|
Fundamental
|
| QM014,318 |
14.318.180
|
30
|
35
|
Fundamental
|
| QM016 |
16.000.000
|
30
|
30
|
Fundamental
|
| QM018 |
18.000.000
|
30
|
25
|
Fundamental
|
| QM018,432 |
18.432.000
|
30
|
25
|
Fundamental
|
| QM020 |
20.000.000
|
30
|
25
|
Fundamental
|
| QM024-FUND |
24.000.000
|
30
|
25
|
Fundamental
|
| QM027 |
27.000.000
|
32
|
50
|
3. Harmonic
|
| QM032 |
32.000.000
|
*
|
50
|
3. Harmonic
|
| QM036 |
36.000.000
|
*
|
50
|
3. Harmonic
|
| QM048 |
48.000.000
|
*
|
50
|
3. Harmonic
|
C = Load Capacitance, RESR = Resistance of Series Resonance, Max., * = Infinitely
|
|
|
