Solid State Ucntrl: 3÷32VDC; 90A; 24÷280VAC Z-Vers.
Varenummer:
107-968
Varekode: CWD2490
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Vis lignende produkter i kategorien "Lastrelæ T. DIN skinne"
• Isolation voltage 4kV
• Zero crossing circuit
• Integrated fingerproof cover
• Operating temperature range -40...+80°C
|
 |
| |
|
|
|
|
|
CWD_ |
UContr |
ULoad |
UDRM |
IT |
ITSM |
|
[V DC] |
[V AC] |
[VPeak] |
[A] |
[A] |
2410 |
3...32 |
24...280 |
600 |
10 |
400 |
2425 |
3...32 |
24...280 |
600 |
25 |
600 |
2450 |
3...32 |
24...280 |
600 |
50 |
850 |
2490 |
3...32 |
24...280 |
600 |
90 |
1350 |
24125 |
3...32 |
24...280 |
600 |
125 |
2000 |
| UContr = Control Voltage, ULoad = Max. Load Voltage (Zero-Voltage Switching), UDRM = Max. Off-State Output Voltage, IT = Max. Effective On-State Current, ITSM = Peak Forward Surge Current |
|
| Additional Products |
| We will also deliver on request all other articles from Crydom, forward orders possible, delivery time approx. 8 weeks. |
|
|
