DC/DC-Conv 9,2-18V:5V 3A 15W
Varenummer:
106-086
Varekode: PSD-15A-5
Vægt: 96 g
0 stk.
på lager
Gruppe:
L8621
MEANWELL DC/DC Converters
Series: PSD-15
Open Frame, Single Output
Input Voltage Ratio: 2:1
Output: 15W
MEANWELL DC/DC Converters
Series: PSD-15
Open Frame, Single Output
Input Voltage Ratio: 2:1
Output: 15W
| Features |
| Open frame Overload protection, pulsing hiccup shutdown, auto recovery Wide input voltage range 2:1 DC decoupling of input and output Input/output insulation 2000V Regulated output voltage Short-circuit proof |
 |
| Technical Specifications |
| |
| Input Voltage: | See Table |
| Over Load Protection: | 105...150% |
| Withstand Voltage | 2000V AC |
| Operating Temperature: | -10...+60C |
| Weight: | 81g |
| |
| Part Nr. | UE | UA | IA | DUA | URN | h |
| [V] | [V] | [A] | [%] | [mVp-p] | [%] | |
| PSD-15A-5 | 9,2...18 | 5 | 0...3 | 2 | 50 | 74 |
| PSD-15A-12 | 9,2...18 | 12 | 0...1,25 | 2 | 100 | 67 |
| PSD-15A-24 | 9,2...18 | 24 | 0...0,6 | 2 | 100 | 72 |
| PSD-15B-5 | 18...36 | 5 | 0...3 | 2 | 50 | 78 |
| PSD-15B-12 | 18...36 | 12 | 0...1,25 | 2 | 100 | 78 |
| PSD-15B-24 | 18...36 | 24 | 0...0,6 | 2 | 100 | 78 |
| PSD-15C-5 | 36...72 | 5 | 0...3 | 2 | 50 | 78 |
| PSD-15C-12 | 36...72 | 12 | 0...1,25 | 2 | 100 | 78 |
| PSD-15C-24 | 36...72 | 24 | 0...0,6 | 2 | 100 | 79 |
| UE = Input Voltage, UA = Output Voltage, IA = Output Current Range, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
| ||||||
| Pin Assignment |
| |
| CN1 | |
| Pin 1: | -UIN |
| Pin 2: | NC |
| Pin 3: | +UIN |
| CN2 | |
| Pin 2: | -UOUT |
| Pin 3: | +UOUT |
| |
| Labelling |
 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
