DC/DC-Conv 18-36V:+3,3V/5A 16,5W
Varenummer:
105-930
Varekode: SDM30-24S3
Vægt: 120 g
0 stk.
på lager
Gruppe:
L8363
MEANWELL DC/DC Converter Modules
Series: SDM30
Single Output
Input Voltage Ratio: 2:1
Output: 16 to 30W
MEANWELL DC/DC Converter Modules
Series: SDM30
Single Output
Input Voltage Ratio: 2:1
Output: 16 to 30W
| Features |
| 2" x 2" housing For direct PCB mounting Wide input voltage range 2:1 DC decoupling of input and output Built-in remote On/Off control Input/output insulation 1000V Regulated output voltage Short-circuit proof |
 |
| Technical Specifications |
| |
| Input Voltage: | See Table |
| Over Load Protection: | >105% |
| Withstand Voltage: | 1000V DC |
| Operating Temperature: | -25...+85C |
| Weight: | 100g |
| |
| Part Nr. | UE | UA | IA | URN | h |
| [V] | [V] | [mA] | [mVp-p] | [%] | |
| SDM30-12S3 | 9,2...18 | 3,3 | 0...5 | 75 | 77 |
| SDM30-12S5 | 9,2...18 | 5 | 0...5 | 75 | 77 |
| SDM30-12S12 | 9,2...18 | 12 | 0...2,1 | 100 | 80 |
| SDM30-12S15 | 9,2...18 | 15 | 0...1,7 | 100 | 80 |
| SDM30-24S3 | 18...36 | 3,3 | 0...5 | 75 | 79 |
| SDM30-24S5 | 18...36 | 5 | 0...5 | 75 | 79 |
| SDM30-24S12 | 18...36 | 12 | 0...2,5 | 100 | 82 |
| SDM30-24S15 | 18...36 | 15 | 0...2 | 100 | 83 |
| SDM30-48S3 | 36...72 | 3,3 | 0...5 | 75 | 80 |
| SDM30-48S5 | 36...72 | 5 | 0...5 | 75 | 80 |
| SDM30-48S12 | 36...72 | 12 | 0...2,5 | 100 | 84 |
| SDM30-48S15 | 36...72 | 15 | 0...2 | 100 | 85 |
| UE = Input Voltage, UA = Output Voltage, IA = Output Current Range, URN = Ripple & Noise, h = Efficiency | |||||
| |||||
| Pin Assignment |
| |
| Pin 1: | +UIN |
| Pin 2: | -UIN |
| Pin 3 ,5: | - |
| Pin 4: | RC |
| Pin 6: | +UOUT |
| Pin 7: | -UOUT |
| Pin 8: | Trim |
| |
| Labelling |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
