SPS Case 480W PFC 15V/32A
Varenummer:
105-534
Varekode: SP-480-15
Vægt: 1796 g
0 stk.
på lager
Gruppe:
L6371
MEANWELL Switching Power Supplies
Series: SP-480
Case, Single Output
Output: 280 to 480W
MEANWELL Switching Power Supplies
Series: SP-480
Case, Single Output
Output: 280 to 480W
| Features |
| Enclosed case, built-in fan, screw terminals Universal input Overload protection, current limiting, auto recovery Protections: short circuit/over load/over voltage Built-in active PFC function Low profile Built-in remote On/Off control Built-in remote sense function |
 |
| Technical Specifications |
| |
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 40A |
| Leakage Current, Max.: | 2mA |
| Over Load Protection | |
| 3,3...5V: | 102...121% |
| 12...48: | 105...135% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 1500V AC |
| O/P-FG: | Short |
| Operating Temperature: | -20...+60C |
| Weight: | 1700g |
| I/P = Input, O/P = Output, FG = Frame Ground | |
| |
| Part Nr. | UA | IA | PA | Uadj | DUA | URN | h |
| [V] | [A] | [W] | [V] | [%] | [mVp-p] | [%] | |
| SP-480-3.3 | 3,3 | 0...85 | 280,5 | 2,9...3,6 | 2 | 80 | 73 |
| SP-480-5 | 5 | 0...85 | 425 | 4,5...5,5 | 2 | 80 | 79 |
| SP-480-12 | 12 | 0...40 | 480 | 10,8...13,2 | 1,5 | 120 | 85 |
| SP-480-15 | 15 | 0...32 | 480 | 13,5...18 | 1,5 | 150 | 85 |
| SP-480-24 | 24 | 0...20 | 480 | 22...27,6 | 1 | 150 | 87 |
| SP-480-48 | 48 | 0...10 | 480 | 41...56 | 1 | 240 | 89 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | |||||||
| |||||||
| Note |
| You will find installation material in product group L6911. |
|
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece Articles in bold print in stock, other articles of 1 piece upwards available on request, delivery time approx. 14 weeks. |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
Inkl. moms
Kr. 1594,69
- v/5 – Kr. 1435,22
- v/10 – Kr. 1250,00
Produktfiler
