AC-DC Enclosed power supply, Output 27VDC 11,9A 321,3W

Varenummer: 105-528
Varekode: RSP-320-27
Vægt: 1166 g
0 stk. på lager
Ved bestilling nu, får vi dem hjem søndag d. 27/9
Vis lignende produkter i kategorien "27V"
Specifikationer
Effekt, max. 321.3  W
Spænding 27  V
Input spænding AC, max. 27  V
Input spænding AC, min. 27  V
Strøm, max. 11.9  A
Features
• Enclosed case, built-in fan, screw terminals
• Universal input
• Overload protection, pulsing hiccup shutdown, auto recovery
• Protections: short circuit/over load/over voltage
• Built-in active PFC function
• Low profile
Technical Specifications

Input Voltage: 88...264V AC (47...63Hz)
124...370V DC
Input Inrush Current, Max.: 40A
Leakage Current, Max.: 1mA
Output Voltage Adjustment: ±10%
Over Load Protection: 105...135%
Withstand Voltage
I/P-O/P: 3000V AC
I/P-FG: 2000V AC
O/P-FG: 500V AC
Operating Temperature: -30...+70°C
Weight: 900g
I/P = Input, O/P = Output, FG = Frame Ground

Part Nr. UA IA PA URN h
  [V] [A] [W] [mVp-p] [%]
RSP-320-2.5 2.5 0...60 150 100 75,5
RSP-320-3.3 3.3 0...60 198 100 79,5
RSP-320-4 4 0...60 240 100 81
RSP-320-5 5 0...60 240 150 83
RSP-320-7.5 7.5 0...40 300 150 88
RSP-320-12 12 0...26,7 320,4 150 88
RSP-320-13.5 13,5 0...23,8 321,3 150 88
RSP-320-15 15 0...21,4 321 150 88,5
RSP-320-24 24 0...13,4 321,6 150 89
RSP-320-27 27 0...11,9 321,3 200 89
RSP-320-36 36 0...8,9 320,4 220 89,5
RSP-320-48 48 0...6,7 321,6 240 90
UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency
Note
These power supplies are considered as a component that has to be installed in a final equipment.
Labelling

Terms of Delivery
Minimum order quantity: 1 PKU = 1 piece
Manufacturer
Inkl. moms
Kr. 587,50
  • v/2 – Kr. 550,00
  • v/10 – Kr. 437,50
Produktfiler
