SPS Case 101W PFC 15V/6,7A
Varenummer:
105-475
Varekode: SP-100-15
Vægt: 750 g
0 stk.
på lager
Gruppe:
L6321
MEANWELL Switching Power Supplies
Series: SP-100
Case, Single Output
Output: 66 to 103W
MEANWELL Switching Power Supplies
Series: SP-100
Case, Single Output
Output: 66 to 103W
| Features |
| Enclosed case, screw terminals Universal input Overload protection, current limiting, auto recovery Protections: short circuit/over load/over voltage Built-in active PFC function |
 |
| Technical Specifications |
| |
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 30A |
| Leakage Current, Max.: | 2mA |
| Output Voltage Adjustment: | +10/-5 |
| Over Load Protection: | 105...150% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 1500V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -10...+60C |
| Weight: | 660g |
| I/P = Input, O/P = Output, FG = Frame Ground | |
| |
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| SP-100-3.3 | 3,3 | 0...20 | 66 | 2 | 100 | 70 |
| SP-100-5 | 5 | 0...20 | 100 | 2 | 100 | 76 |
| SP-100-7.5 | 7,5 | 0...13,5 | 101,2 | 2 | 100 | 78 |
| SP-100-12 | 12 | 0...8,5 | 102 | 2 | 100 | 80 |
| SP-100-13.5 | 13,5 | 0...7,5 | 101,2 | 2 | 100 | 80 |
| SP-100-15 | 15 | 0...6,7 | 100,5 | 2 | 100 | 82 |
| SP-100-24 | 24 | 0...4,2 | 100,8 | 1 | 150 | 84 |
| SP-100-27 | 27 | 0...3,8 | 102,6 | 1 | 150 | 83 |
| SP-100-48 | 48 | 0...2,1 | 100,8 | 1 | 250 | 82 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
| ||||||
| Note |
| You will find installation material in product group L6911. |
|
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
