SPS DIN-Rail 24W 24V/1A
Varenummer:
105-320
Varekode: MDR-20-24
Vægt: 180 g
0 stk.
på lager
Gruppe:
L5132
MEANWELL Switching Power Supplies
Series: MDR-20
DIN-Rail Assembly, Single Output
Output: 15 to 24W
MEANWELL Switching Power Supplies
Series: MDR-20
DIN-Rail Assembly, Single Output
Output: 15 to 24W
| Features |
| Direct assembly on DIN Rail Enclosed case, Touch-guard screw terminals Universal input Overload protection, current limiting, auto recovery Protections: short circuit/over load/over voltage Power-on LED display Low no load power consumption DC OK signal NEC Class 2 compliant |
 |
| Technical Specifications |
| |
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 40A |
| Leakage Current, Max.: | 1mA |
| Output Voltage Adjustment: | ±10% |
| No Load Power Consumption, Max.: | 0,75W |
| Over Load Protection: | 105...160% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 1500V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -20...+70C |
| Weight: | 190g |
| I/P = Input, O/P = Output, FG = Frame Ground | |
| |
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| MDR-20-5 | 5 | 0...3 | 15 | 2 | 80 | 76 |
| MDR-20-12 | 12 | 0...1,67 | 20 | 1 | 120 | 80 |
| MDR-20-15 | 15 | 0...1,34 | 20 | 1 | 120 | 81 |
| MDR-20-24 | 24 | 0...1 | 24 | 1 | 150 | 84 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
| ||||||
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
