  5. SPS Class2 PFC 75W 15V/5A

SPS Class2 PFC 75W 15V/5A

Varenummer: 105-292
Varekode: PLN-100-15
Vægt: 625 g
0 stk. på lager
Ved bestilling nu, får vi dem hjem fredag d. 25/9
Vis lignende produkter i kategorien "For CV LED/Constant Voltage"
Gruppe: L4766
MEANWELL LED Switching Power Supplies
Series: PLN-100
Indoor and Outdoor Installations (IP64)
Output: 60 to 96W
Features
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• IP64, for indoor and outdoor installations
• Suitable for LED lighting and moving sign applications
• UL1310 Class 2
• Adjustable output voltage
• Adjustable output current
• EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Technical Specifications
Input Voltage:
90...295V AC (47...63Hz)
127...417V DC
Input Inrush Current, Max.:
40A
Over Current Protection:
95...102%
Withstand Voltage
I/P-O/P:
3750V DC
I/P-FG:
1880V DC
O/P-FG:
500V DC
Operating Temperature:
-30...+50°C
Weight:
520g
I/P = Input, O/P = Output, FG = Frame Ground

Part Nr.
UA
Uadj
Iadj
IA
PA
DUA
URN
h
PLN-_
[V]
[V]
[A]
[A]
[W]
[%]
[mVp-p]
[%]
100-1212
10,2...12
3,75...5
5
60
3
150
84,5
100-1515
12,8...15
3,75...5
5
75
3
150
86,5
100-2020
17...20
3,6...4,8
4,8
96
3
150
90
100-2424
20,4...24
3...4
4
96
3
150
90
100-2727
23...27
2,6...3,55
3,55
95,85
3
150
90
100-3636
30,6...36
2...2,65
2,65
95,4
2
150
90
100-4848
40,8...48
1,5...2
2
96
2
200
89
UA = Output Voltage, Uadj = Output Voltage Adjustment, Iadj = Output Current Adjustment, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Typ. Efficiency
Note
Suitable for indoor use and outdoor use without direct sunlight exposure.
You will find suitable High Power LED Modules starting at product group W1982.
Labelling
(only 48V), (except 48V),
Terms of Delivery
Minimum order quantity: 1 PKU = 1 piece
Manufacturer

http://www.meanwell.com
Inkl. moms
Kr. 562,50
  • v/10 – Kr. 437,50
  • v/25 – Kr. 375,00
  • v/100 – Kr. 325,00
