SPS Plug-in 5W 5V/1A (2,1/5,5 DC-stik)
Varenummer:
105-121
Varekode: GS06E-1P1J
Vægt: 111 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Gruppe: L4246
MEANWELL Plug-in Switching Power Supplies
Series: GS06E
Output: 5 to 6W
| Features |
| • Plug-in switching power supply with europlug • Universal input • Overload protection, pulsing hiccup shutdown, auto recovery • Protections: short circuit/over load/over voltage • Insulation Class II • Low no load power consumption |
 |
| Technical Specifications |
|
|||||||||||||||||||
| Input Voltage: | 90...264V AC (47...63Hz) | 127...370V DC | Input Inrush Current, Max.: | 50A | No Load Power Consumption, Max.: | 0,3W | Operating Temperature: | 0...+40°C | Cable Length: | 1,8m | Input Plug: | Euro | Output Plug, Coax: | 2,1x5,5mm | Weight: | 100g | |||
|
|||||||||||||||||||
| Part Nr. | UA | IA | PA | DUA | URN | h | [V] | [A] | [W] | [%] | [mVp-p] | [%] | GS06E-1P1J | 5 | 0...1 | 5 | 5 | 50 | 67 | GS06E-11P1J | 7,5 | 0...0,8 | 6 | 5 | 80 | 72 | GS06E-2P1J | 9 | 0...0,66 | 6 | 5 | 80 | 74 | GS06E-3P1J | 12 | 0...0,5 | 6 | 3 | 100 | 76 | GS06E-4P1J | 15 | 0...0,4 | 6 | 3 | 120 | 77 | GS06E-5P1J | 18 | 0...0,33 | 6 | 3 | 150 | 78 | GS06E-6P1J | 24 | 0...0,25 | 6 | 2 | 180 | 80 | GS06E-8P1J | 48 | 0...0,125 | 6 | 2 | 200 | 82 | ||||||||
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Labelling |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.meanwell.com |
|
Inkl. moms
Kr. 149,00
