DIN-Rail Terminal 4mm² Blue
Varenummer:
104-498
Varekode: SR4BL
Vægt: 10 g
0 stk.
på lager
Ved bestilling nu, får vi dem hjem tirsdag d. 10/11
Gruppe:
F9612
PTR DIN-Rail Terminals
Series: SR4
For TS35
PTR DIN-Rail Terminals
Series: SR4
For TS35
| Features |
| • Reliable connection of the conductor without any special preparation • Vibration-proof and gastight connections • Connect and disconnect of the conductor by using a screw-driver • Color: beige, blue, green/yellow |
 |
| SR4_ |
|
| Technical Specifications |
| |
| Rated Voltage | |
| UL, CSA: | 600V |
| IEC 947-7-1: | 800V |
| Rated Current | |
| UL, CSA: | 20A |
| IEC 947-7-1: | 32A |
| Rated Cross Section | |
| Solid Wire: | 0,2...6mm2 |
| Stranded Wire: | 0,2...4mm2 |
| Dimensions: | 48x6x52mm |
| Stripped Length: | 12mm |
| Tightening Torque: | 1,0Nm |
| |
| SRSL4-T35 |
|
| Technical Specifications |
| |
| Rated Cross Section, Max. | |
| Solid Wire: | 0,2...6mm2 |
| Stranded Wire: | 0,2...4mm2 |
| Dimension: | 56x8x47mm |
| Stripped Lenght: | 12mm |
| Tightening Torque: | 1,0Nm |
| |
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.ptr-messtechnik.de |
|
Inkl. moms
v/5
Kr. 7,04
- v/25 – Kr. 5,86
- v/100 – Kr. 4,69
- v/1000 – Kr. 3,52
