Relay SPST 16A 24V 1440R
Varenummer:
103-879
Varekode: RT334-24
Vægt: 14 g
17 stk.
på lager
Bestil nu for afsendelse i morgen
Yderligere 500 stk. kan skaffes mandag d. 9/11
Specifikationer
| Relæ kontakt | SPST |
|---|---|
| Spolespænding | 24 V |
| Mærkestrøm | 16 A |
| Spolemodstand | 1.44 kΩ |
Gruppe:
E6371
TE Power PCB Relays
Series: RT
Contact: SPDT, DPDT or SPST-NO
Rated Current: 8A, 12A, 16A
Housing: 29,0x12,7x15,7mm
TE Power PCB Relays
Series: RT
Contact: SPDT, DPDT or SPST-NO
Rated Current: 8A, 12A, 16A
Housing: 29,0x12,7x15,7mm
| Features |
| Sensitive reel 400mW 5kV/10mm coil contact Protection class RTII Insulation to IEC60664-1 |
 |
| Technical Specifications |
| |
| Contact | |
| RT114_,RT314_: | SPDT |
| RT424_: | DPDT |
| RT334_: | SPST-NO |
| Contact Material: | AgNi 90/10 |
| Rated Current | |
| RT114_: | 12A |
| RT314_ RT334_: | 16A |
| RT424_: | 8A |
| Max. Switching Voltage: | 240/400V AC |
| Max. Switching Power | |
| RT114_ (12A): | 3000VA |
| RT314_ RT334_ (16A): | 4000VA |
| RT424_ (8A): | 2000VA |
| Creepage/Clearance: | ³10/10mm |
| Operate/Release Time: | 7/3ms |
| Testing Voltage | |
| Coil/Contact: | 5000Vrms |
| Opening Contact: | 1000Vrms |
| Lifetime Mechanical | |
| DC-Coil: | >30x106 Operations |
| AC-Coil: | >10x106 Operations |
| Operating Temperature | |
| DC-Coil: | -40...+85C |
| AC-Coil: | -40...+70C |
| Weight Approx.: | 14g |
| |
| Coil Data |
| Part Nr. | UN | UAn | UAb | PN | RN |
| [V DC/AC] | [V] | [V] | [mW/VA] | [W] | |
| RT_-12 | 12 | 8,4 | 1,2 | 400 | 360 |
| RT_-24 | 24 | 16,8 | 2,4 | 400 | 1440 |
| RT_-AC230 | 230 | 172,5 | 34,5 | 0,74 | 32500 |
| UN = Rated Voltage, UAn = Operate Voltage, UAb = Release Voltage, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 23C | |||||
| |||||
| Approvals |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces RT_-AC230: 1 PKU = 5 pieces |
|
| Manufacturer |
| TE Connectivity http://www.te.com |
|
Inkl. moms
Kr. 34,13
- v/10 – Kr. 25,59
- v/25 – Kr. 21,33
- v/100 – Kr. 17,06
- v/1000 – Kr. 12,80
Produktfiler
