Relay SPST-NO 6A 5V 125R RE030005
Varenummer:
103-866
Varekode: RE300-5
Vægt: 5 g
0 stk.
på lager
Gruppe:
E6333
TE Power PCB Relays
Series: RE
Contact: SPST-NO
Rated Current: 6A
Housing: 20,0x10,0x10,6mm
E6333
TE Power PCB Relays
Series: RE
Contact: SPST-NO
Rated Current: 6A
Housing: 20,0x10,0x10,6mm
| Features |
| • Sensitive coil 200mV • 4kV coil-contact • Washtight RTIII • Insulation according to IEC 60664-1 |
 |
| Application |
| PLCs, timers, temperature control, I/O cards, white goods |
|
| Technical Specifications |
| |
| Contact: | SPST-NO (Single Contact) |
| Contact Material: | AgCdO |
| Rated Current: | 6A |
| Max. Switching Current (4s): | 15A |
| Max. Switching Voltage: | 400V AC |
| Max. Switching Power: | 1500VA |
| Creepage/Clearance: | 4/4mm |
| Operate/Release Time: | 10/5ms |
| Testing Voltage | |
| Coil/Contact: | 4000Vrms |
| Opening Contact: | 1000Vrms |
| Lifetime | |
| Mechanical: | >30x106 Operations |
| Electrical (6A, 250V AC): | 1x105 Operations |
| Operating Temperature: | -40...+70°C (+85°C at 4A) |
| Weight Approx.: | 5g |
| |
| Coil Data |
| Part Nr. | UN | UAn | UAb | IN | PN | RN |
| [V DC] | [V] | [V] | [mA] | [mW] | [W] | |
| RE300-5 | 5 | 3,5 | 0,5 | 200 | 125 | |
| RE300-12 | 12 | 8,4 | 1,2 | 16,6 | 200 | 720 |
| RE300-24 | 24 | 16,8 | 2,4 | 8,3 | 200 | 2880 |
| UN = Rated Voltage, UAn = Operate Voltage, UAb = Release Voltage, RN = Coil Resistance; All Specifications Measured at 23°C | ||||||
| ||||||
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
| TE Connectivity http://www.te.com |
|
Inkl. moms
Kr. 32,13
- v/10 – Kr. 27,22
- v/25 – Kr. 23,52
- v/100 – Kr. 18,56
- v/1000 – Kr. 13,61
