SCHURTER SMD Fuse Holder 5x20 horizontal
Varenummer:
103-625
Varekode: 3101.0075
Vægt: 5 g
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Gruppe:
E1828
SCHURTER SMD Fuse Holders
Series: FPG7
For Microfuses 5x20mm
Terminals: SMD
Rated Current: Up to 10A
E1828
SCHURTER SMD Fuse Holders
Series: FPG7
For Microfuses 5x20mm
Terminals: SMD
Rated Current: Up to 10A
| Features |
| • SMD Terminals • FPG7-70: slotted for screwdriver, IP40 • FPG7-75: fingergrip to open by hand, IP40 |
 |
| Technical Specifications |
| |
| Rated Voltage: | 250V |
| Rated Current: | 10A |
| Rated Power Acceptance (23°C): | 2,5W |
| Temperature Range: | -40...+85°C |
| Torque, Max. (Nut): | 1,2Nm |
| Shocksafe Category: | PC2 |
| |
| Note |
| • You will find suitable fuse links starting at product group E1421. |
|
| Norms |
| IEC60127-6, UL512, CSA C22.2-39 |
|
| Approvals |
10A/250V: 16A/250V:  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.schurter.de |
|
