SCHURTER SMD Fuse Holder 5x20/6,3x32mm. horizontal
Varenummer:
103-622
Varekode: 0031.8241
Vægt: 4 g
0 stk.
på lager
Ved bestilling nu, får vi dem hjem lørdag d. 31/10
Gruppe:
E1821
SCHURTER SMD Fuse Holders
Series: OGD
For Microfuses 5x20mm and 6,3x32mm
Terminals: SMD
Rated Current: Up to 10A
E1821
SCHURTER SMD Fuse Holders
Series: OGD
For Microfuses 5x20mm and 6,3x32mm
Terminals: SMD
Rated Current: Up to 10A
| Features |
| For SMD assembly Fuse block accepts 5x20mm and 6,3x32mm fuse links Low profile fuse block with insulation walls Special clips-ends prevent axial fuse-link movement |
 |
| Technical Specifications |
| |
| Rated Voltage: | 250V (UL: 500V) |
| Rated Current: | 10A (UL: 16A) |
| Rated Power Acceptance (23C): | 4W |
| Temperature Range: | -40...+85C |
| Contact Resistance: | £5mW |
| Socket, Thermoplastic: | UL94V-0 |
| |
| Note |
| You will find suitable fuse links starting at product group E1421. |
|
| Norms |
| IEC60127-6, UL512, CSA C22.2-39 |
|
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.schurter.de |
|
