SMD Crystal Oscillator 16,000000 MHz
Varenummer:
103-333
Varekode: SG615PC-16
0 stk.
på lager
Kontakt os for at få oplyst leveringstid
Vis lignende produkter i kategorien "SMD"
• Suitable for CMOS and TTL
• High reliability due to cylindrical AT crystal
• Low power consumption
|
 |
|
|
|
Frequency Range:
|
1,8432...50MHz
|
Frequency Stability:
|
±100ppm
|
Operating Voltage:
|
5±0,5VDD
|
Maximum Voltage:
|
-0,3...+7VDD-GND
|
Output Voltage
|
VOH1), Min.:
|
VDD- 0,4V
|
VOL2) , Max.:
|
0,4V
|
Output Current
|
IOH1):
|
-0,4mA
|
IOL2):
|
SG-615P:
|
16mA
|
SG-615PH:
|
4mA
|
Operating Temperature:
|
-20...+70°C
|
Storage Temperature:
|
-55...+125°C
|
Aging, Max.:
|
5ppm/Year
|
Solder Temperature, Max.:
|
£260°C/10s
|
Shock Resistance:
|
±20ppm
|
Suitable for:
|
CMOS, TTL
|
1) VOH, IOH = "1"-Level, 2) VOL, IOL = "0"-Level
|
|
|
