Transformer 14VA 2x115V 2x18V 2x389mA
Varenummer:
103-258
Varekode: BVUI3930062
Vægt: 335 g
0 stk.
på lager
Specifikationer
| Produkt | transformator |
|---|---|
| Strøm, max. (sekundærvikling) | 2x389mA |
| Sekundær | 2x18V |
| Primær | 2x115V |
| AC Effekt, max. | 14 VA |
| Construction |
| • Vacuum encapsulated, bobbin with two chambers • Leads through soldering pins to accommodate PCB mounting • Designed to match VDE 0570 regulations • Fully tested at primary and secondary voltage of 6000V, leakage and sparking distance in air is at least 10mm • Types with double primary and secondary windings (2x115V) suitable for application in 115V as well as 230V power supplies |
 |
| Electrical Specifications |
| Part Nr. | P1) | Secondary | Secondary | No-Load |
| Voltage | Current2) | Voltage | ||
| [VA] | [V] | [mA] | [V] | |
| BVUI3930085 | 14 | 2x6 | 2x1166 | 8,3 |
| BVUI3930074 | 14 | 2x9 | 2x778 | 12,4 |
| BVUI3930081 | 14 | 2x12 | 2x583 | 16,5 |
| BVUI3930062 | 14 | 2x18 | 2x389 | 24,7 |
| BVUI3930096 | 14 | 2x21 | 2x334 | 28,8 |
| BVUI3940086 | 18 | 2x6 | 2x1500 | 8,7 |
| BVUI3940073 | 18 | 2x7,5 | 2x1200 | 10,2 |
| BVUI3940063 | 18 | 2x9 | 2x1000 | 13,0 |
| BVUI3940087 | 18 | 2x12 | 2x750 | 16,7 |
| BVUI3940088 | 18 | 2x15 | 2x600 | 20,4 |
| BVUI3940075 | 18 | 2x18 | 2x500 | 23,6 |
| BVUI3940097 | 18 | 2x21 | 2x428 | 24,7 |
| BVUI3950098 | 24 | 2x9 | 2x1333 | 11,4 |
| BVUI3950091 | 24 | 2x12 | 2x1000 | 14,9 |
| BVUI3950083 | 24 | 2x15 | 2x800 | 18,5 |
| BVUI3960102 | 30 | 2x9 | 2x1666 | 11,3 |
| BVUI3960079 | 30 | 2x12 | 2x1250 | 15,0 |
| BVUI3960103 | 30 | 2x15 | 2x1000 | 18,6 |
| P = Power, 1) Primary Voltage at 230V, 2) Secondary Voltage per Winding ±5% | ||||
| ||||
| Size |
| Performance | Height h | Weight | |
| [mm] | [g] | ||
| 14VA | 25,2 | 330 | |
| 18VA | 28,5 | 390 | |
| 24VA | 32,0 | 460 | |
| 30VA | 36,0 | 550 | |
| |||
| Approvals |
    05 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece Articles in bold print in stock, other articles of 100 pieces upwards available on request, delivery time approx. 5 weeks. |
|
| Manufacturer |
HAHN GmbH & Co. KG |
| http://www.hahn-trafo.com |
|
