El-Capacitor 4700µF/63V-P10 30x36mm

Name: El-Capacitor 4700µF/63V-P10 30x36mm
SKU: 102958
Price: 62.50 DKK
Availability: InStock

Varenummer: 102-958

Varekode: CSHT4700/63

Vægt: 37 g

7 stk. på lager

Vis lignende produkter i kategorien "63V"

Specifikationer

Kondensator-type	radial
Produkt	kondensator
Spænding, max.	63 V
Tolerance	±20 %
Temperatur	-40 – 105 °C
Højde	3.6 cm
Diameter	3 cm
Benafstand	1 cm
Kapacitans	4 700 µF

Gruppe: C6471
JAMICON Electrolytic Capacitors
Series: HSW
Snap-In
Style: Bulk
Rated Voltage: 25...450V DC
Tolerance: 20%
Temperature Range: -40...+105°C

Technical Specifications


Operating Temperature Range:	-40...+105°C	Leakage Current (Peak Value after 5min.):	I_L£0,02xCxU_N or 3mA

	Part Nr.	C	U_N	tand	I_R	Z	D	L	[µF]	[V=]	[A]	[V/A]	[mm]	[mm]	HSW0047/450	47	450	0,15	0,39	6	22	25	HSW0100/400	100	400	0,15	0,61	6	22	30	HSW0220/400	220	400	0,15	1,16	6	30	35	HSW0470/400	470	400	0,15	2,07	6	35	45	HSW1000/63	1000	63	0,30	0,91	3	22	25	HSW2200/50	2200	50	0,35	1,31	4	22	30	HSW4700/35	4700	35	0,40	1,65	6	22	35	HSW4700/50	4700	50	0,35	1,74	4	25	35	HSW4700/63	4700	63	0,30	1,84	3	30	35	HSW6800/35	6800	35	0,35	1,94	6	25	40	HSW10000/35	10000	35	0,40	2,03	6	30	35	HSW10000/50	10000	50	0,35	2,39	4	30	45	HSW15000/35	15000	35	0,40	2,92	6	35	40	HSW22000/25	22000	25	0,25	3,55	6	35	40
C = Capacitance, U_N = DC Voltage Rating, tan d = Dissipation Factor (120Hz, 25°C), I_R = Ripple Current (120Hz, 85°C), Z = Impedance Ratio (120Hz, -25...+25°C)

Terms of Delivery

Minimum order quantity: 1 PKU = 5 pieces

Manufacturer

http://www.jamicon.com.tw

Inkl. moms

Kr. 62,50

v/10 – Kr. 51,25
v/25 – Kr. 49,38
v/50 – Kr. 46,25
v/100 – Kr. 42,00
v/1000 – Kr. 21,00

Produktfiler

Datasheet
