El-Capacitor 1000µF/25V 12,5x20 P5
| Kondensator-type | radial |
|---|---|
| Produkt | kondensator |
| Spænding, max. | 25 V |
| Tolerance | ±20 % |
| Temperatur | -55 – 105 °C |
| Højde | 2 cm |
| Diameter | 1.25 cm |
| Benafstand | 5 mm |
| Kapacitans | 1 000 µF |
Type
Aluminum electrolytic capacitor
Capacity
1.000 µF
Capacity Tolerance
±20
Rated voltage DC
25 V
Assembly Type
THT
Housing
radial
Pitch
5 mm
Operating Temperature Min.
-55 °C
Operating Temperature Max.
105 °C
RoHS-Conform
Specifications
Open all
General
Manufacturer
Jamicon
Type
Aluminum electrolytic capacitor
Series
TL
Product group
C6395
Housing
radial
Applications
Suitable for electronic ballast, adaptor and switching power.
Assembly Type
THT
Form of Delivery
bulk
Connections
2Pin
Features
Low impedance and long life with standing 5000 hours load life.
