SMD Resistor 5% 4x15K
Varenummer:
102-526
Varekode: SNR06034K015-5
Vægt: 0 g
0 stk.
på lager
Specifikationer
| Tolerance | ±5 % |
|---|---|
| Modstand | 15 kΩ |
| Effekt, max. | 0.063 W |
Gruppe:
C1931
VISHAY, ROHM SMD Resistor Networks
Series: MNR14, CRA06S
Power: 0,063W
Tolerance: 5%
Housing: 4x0603
VISHAY, ROHM SMD Resistor Networks
Series: MNR14, CRA06S
Power: 0,063W
Tolerance: 5%
Housing: 4x0603
| Features |
| for High-density mounting Convex Terminations 8 Terminal Package with 4 isolated Resistors |
 |
| Technical Specifications |
| |
| Tolerance: | ±5% |
| Power Rating (70C): | 0,063W |
| Operating Voltage, Max.: | 50Vrms |
| Insulation Resistance: | >10MW |
| Insulation Voltage (1 Min): | 100V AC/DC |
| Temperature Coefficient: | ±200ppm/K |
| Temperature Range: | - 55C...+155C |
| Derating: | Linear from 70C to 125C (0W) |
| |
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 100 pieces Form of delivery: orders of less than 5000 pieces: 100 pieces on tape segment without leader tape and reel; orders of 5000 pieces: 5000 pieces on 180mm reel on papertape. |
|
| Manufacturer |
  |
| http://www.rohm.com http://www.vishay.com |
|
