SMD Resistor 5% 4x2,2K

Varenummer: 102-521
Varekode: SNR06034K002,2-5
Vægt: 0 g
0 stk. på lager
Vis lignende produkter i kategorien "SMD 4x0603"
Specifikationer
Tolerance ±5  %
Modstand 2.2  kΩ
Effekt, max. 0.063  W
Features
• for High-density mounting
• Convex Terminations
• 8 Terminal Package with 4 isolated Resistors
Technical Specifications
Resistance Value:
 Row E12
Tolerance:
 ±5%
Power Rating (70°C):
 0,063W
Operating Voltage, Max.:
 50Vrms
Temperature Coefficient:
 ±200x10-6/K
Temperature Range:
 - 55°C...+125°C
Derating:
 Linear from 70°C to 125°C (0W)
Manufacturer
Rohm,
http://www.rohm.com
http://www.vishay.com
Inkl. moms
v/100 Kr. 0,45
  • v/1000 – Kr. 0,22
  • v/10000 – Kr. 0,15
