Printterminal 2-POLET 300V/7A, 100 stk. (BEMÆRK: 3,5mm benafstand!)

Varenummer: 100-300
Varekode: DG350R-3.5-02P
83 stk. på lager
Vis lignende produkter i kategorien "RM 3,5mm."
Capability
Rated voltage/Rated current
300V/7A
Wire range
24-18 AWG, 1.0 mm2
Withstanding voltage
AC2000V/1Min
Insulation resistance
5000MΩ/DC1000V
Contact resistance
20 mΩ
Temp. Range
-40°C~+105°C
Torque
0.2N.m (1.7Lb.in)
Strip length
4.5-5 mm

Specification
Housing
PA66, UL94V-0
Screws
M2, steel, Zinc plated
Wire guard
Phosphor bronze, Ni plated
Pin header
Brass, Tin plated

DEGSON

Inkl. moms
Kr. 49,00
Kr. 190,00
  • v/15 – Kr. 75,00
  • v/60 – Kr. 65,00
