Strømforsyning 15V, 1200mA
Varenummer:
115-122
Varekode: HNP18-150
Vægt: 133 g
0 stk.
på lager
- Strømforsyning 15V, 1,2A
- Stik 5.5 x 2.1 rund cylinder
- Kabel: 1,5 meter
Gruppe: L4255
HN-POWER Plug-in Switching Power Supplies
Series: HNP18
Output: 15 to 18W
| Features |
| • Plug-in switching power supply with europlug • Universal input • Protections: short circuit/over load/over voltage • Insulation Class II • Low no load power consumption |
 |
| Technical Specifications |
|
|||||||||||||||
| Input Voltage: | 90...264V AC (47...63Hz) | Input Inrush Current, Max.: | 30A | No Load Power Consumption, Max.: | 0,4W | Operating Temperature: | -5...+45°C | Cable Length: | 1,5m | Output Plug: | 2,1x5,5mm | Weight: | 130g | ||
|
|||||||||||||||
| Part Nr. | UA | IA | PA | URN | h | [V] | [A] | [W] | [mVp-p] | [%] | HNP18-050 | 5 | 0...3 | 15 | 100 | 80 | HNP18-090 | 9 | 0...2 | 18 | 100 | 80 | HNP18-120 | 12 | 0...1,5 | 18 | 100 | 80 | HNP18-150 | 15 | 0...1,2 | 18 | 100 | 80 | |||||||
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, URN = Typ. Ripple & Noise, h = Typ. Efficiency | |||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||
| Labelling |
 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
| HN-Power |
|
