TFT-LCD-Graphicm 115,2x86,4mm 320x240 Fu
Varenummer:
107-763
Varekode: VGG322404-6UFLWA
Vægt: 223 g
0 stk.
på lager
Gruppe:
W6885
EVERVISION LCD-Graphic-Modules TFT Coloured
Series: VGG_
EVERVISION LCD-Graphic-Modules TFT Coloured
Series: VGG_
| Technical Specifications |
| High contrast LCD-TFT display Full-Colour White LED backlight 3x8-Bit resp. 3x6-Bit Parallel RGB Operating temperature range -20...+70C |
 |
| VGG_ | Type | Format | A-Area | LxWxD |
| [HxV] | [mm] | [mm] | ||
| 322419-6_A | TFT | 320x240 | 70,08x52,56 | 76,9x63,9x3,3 |
| 322425-6_A | TFT | 320x240 | 70,08x52,56 | 76,9x63,9x3,3 |
| 322403-7_E | TFT | 320x240 | 115,2x86,4 | 144x104,6x13 |
| 322404-6_A | TFT | 320x240 | 115,2x86,4 | 167x109x8,9 |
| 322426-7_A | TFT | 320x240 | 115,2x86,4 | 144x104,6x13 |
| 482709-6_A | TFT | 480x272 | 95,04x53,86 | 105,5x67,2x3,1 |
| 644803-6_E | TFT | 640x480 | 115,2x86,4 | 144x104,6x13 |
| 804807-6_A | TFT | 800x480 | 108,0x64,8 | 118,5x77,6x3,4 |
| 804806-6_A | TFT | 800x480 | 152,4x91,44 | 166,6x109,4x10 |
| TFT = Thin Film Transistor, H = Horizontal (Pixel), V = Vertical (Pixel), A-Area = Active Area | ||||
| ||||
| VGG_ | P-Size | Backl | B-Colour | Tamb |
| [mm] | [C] | |||
| 322419-6_A | 0,219x0,219 | LED | White | -20...+70 |
| 322425-6_A | 0,219x0,219 | LED | White | -20...+70 |
| 322403-7_E | 0,360x0,360 | LED | White | -20...+70 |
| 322404-6_A | 0,360x0,360 | LED | White | -20...+70 |
| 322426-7_A | 0,360x0,360 | LED | White | -20...+70 |
| 482709-6_A | 0,198x0,198 | LED | White | -20...+70 |
| 644803-6_E | 0,180x0,180 | LED | White | -20...+70 |
| 804807-6_A | 0,135x0,135 | LED | White | -20...+70 |
| 804806-6_A | 0,1905x0,1905 | LED | White | -20...+70 |
| P-Size = Pixel Size, Backl = Backlight, B-Colour = Backlight Colour, Tamb = Ambient Operating Temperature | ||||
| ||||
| Suitable Connectors |
| VGG_ | Backlight | Touch Panel | Interface |
| PCB-Side | PCB-Side | PCB-Side | |
| 322419-6_A | via 54Pin FPC | - | FPC0,50-B-054U |
| 322425-6_A | via 54Pin FPC | - | FPC0,50-B-054U |
| 322403-7_E | STL135CSPTT-2 | - | FPC0,50-B-033U1) |
| 322404-6_A | STL135CSPTT-2 | - | FPC0,50-B-040U2) |
| 322426-7_A | STL135CSPTT-2 | - | FPC0,50-B-033U1) |
| 482709-6_A | FPC0,50-B-004U | - | FPC0,50-B-040U |
| 644803-6_E | STL135CSPTT-2 | - | FPC0,50-B-033U1) |
| 804807-6_A | - | ||
| 804806-6_A | STL135CSPTT-2 | - | FPC0,50-B-040U2) |
| 1) 33Pin FFC-Cable required, 2) 40Pin FFC-Cable required | |||
| |||
| Note |
| You will find the suitable connectors for the displays in our blue "Passive and Electomechanical Components" catalogue at product group F4911. |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
 |
| http://www.evervisionlcd.de |
|
